Shape memory phenomena and twinning detwinning reactions governing reversibility in shape memory alloys

Shape memory alloys are energetic materials and take place in advanced smart materials by exhibiting dual memory characteristics, shape memory effect and superelasticity, with recoverability of two shapes at different condition. Shape memory effect is initiated with thermomechanical processes on cooling and deformation and performed thermally on heating and cooling, with which shape of the material cycles between original and deformed shapes in reversible way. This is plastic deformation, due to the soft character of material in low temperature condition, with which strain energy is stored and released on heating by recovering original shape. Therefore, this behavior can be called mechanical memory or thermoelasticity. Shape memory effect is governed by crystallographic transformations, thermal and stress induced martensitic transformations. Thermal induced martensitic transformation occurs on cooling with cooperative movement of atoms in <110 > -type directions on {110} - type close packed planes of austenite matrix, along with lattice twinning and ordered parent phase structures turn into the twinned martensite structures, and twinned structures turn into detwinned martensite structures by means of stress induced martensitic transformations with deformation.  Superelasticity is performed with stressing and releasing the material in elasticity limit at a constant temperature in the parent austenite phase region, and shape recovery occurs immediately upon releasing, by exhibiting elastic material behavior. It is important that stressing and releasing paths are different in stress-strain diagram, and hysteresis loop refers to energy dissipation. These alloys are functional materials and used in many fields in biomedical application to the building industry as the energy absorber against seismic events. These alloys are functional materials and used in many fields in biomedical application to the building industry as the energy absorber against seismic events. Superelasticity is also result of stress induced martensitic transformation, and the ordered parent phase structures turn into the detwinned martensite structures with stressing. Lattice twinning and detwinning reactions play important role in shape reversibility and martensitic transformations, and they are driven by internal and external forces, by means of inhomogeneous lattice invariant shears.

Copper based alloys exhibit this property in metastable β-phase region. Lattice twinning is not uniform in these alloys, and the ordered parent phase structures undergo the layered structures with martensitic transformation.

In the present contribution, x-ray and electron diffraction studies were carried out on ternary copper based CuZnAl and CuAlMn alloys. X-ray diffraction profiles and electron diffraction patterns exhibit super lattice reflections. A series of x-ray diffractogram were taken during aging. X-ray diffractograms taken in a long-time interval show that locations and intensities of diffraction peaks change with the aging time at room temperature, and this result refers to the redistribution of atoms in diffusive manner.

Keywords: Shape memory effect, martensitic transformation, thermoelasticity, superelasticity, twinning, detwinning.

Dr. Adiguzel graduated from Department of Physics, Ankara University, Turkey in 1974 and received PhD- degree from Dicle University, Diyarbakir-Turkey. He has studied at Surrey University, Guildford, UK, as a post-doctoral research scientist in 1986-1987, and studied on shape memory alloys. He worked as research assistant, 1975-80, at Dicle University and shifted to Firat University, Elazig, Turkey in 1980. He became professor in 1996, and he has been retired on November 28, 2019, due to the age limit of 67, following academic life of 45 years. He published over 80 papers in international and national journals; He joined over 120 conferences and symposia in international and national level as participant, invited speaker or keynote speaker with contributions of oral or poster. He served the program chair or conference chair/co-chair in some of these activities. In particular, he joined in last six years (2014 - 2019) over 60 conferences as Keynote Speaker and Conference Co-Chair organized by different companies. Also, he joined over 180 online conferences in the same way in pandemic period of 2020-2023. He supervised 5 PhD- theses and 3 M. Sc- theses. Dr. Adiguzel served his directorate of Graduate School of Natural and Applied Sciences, Firat University, in 1999-2004. He received a certificate awarded to him and his experimental group in recognition of significant contribution of 2 patterns to the Powder Diffraction File – Release 2000. The ICDD (International Centre for Diffraction Data) also appreciates cooperation of his group and interest in Powder Diffraction File.
